New Dynamic Series Air Curtain — 900–2000 mm | Up to 3,960 m³/h
Keep conditioned air in and dust/insects out with the New Dynamic Series air curtain. This ambient (unheated) range delivers a reliable air barrier with quiet operation and a sleek RAL 9005 (black) finish — ideal for restaurants, hotels, cafés, and retail entrances. Max air range up to 2.5 m.
Key Features
- Six sizes: 900, 1000, 1200, 1500, 1800, 2000 mm to match common door widths.
- Airflow up to 3,960 m³/h with outlet velocity 11–12 m/s (model dependent).
- Two fan speeds: Low / High via simple key switch control.
- Quiet performance: ≤45–51 dB depending on model.
- Standard color: RAL 9005; custom RAL colors available on request.
- Optional integrations: BMS (RS-485 Modbus RTU), auto-restart, fire alarm link, door sensor, IR remote.
Unit Dimensions
A (length): 900 / 1000 / 1200 / 1500 / 1800 / 2000 mm | B: 180 mm | C: 185 mm | D: 220 mm
Primary Parameters
| Model | Width (mm) | Voltage (V) | Frequency (Hz) | Power (W) | Net Weight (kg) | Dimensions L×W×H (mm) |
|---|---|---|---|---|---|---|
| FRX1209 YDN/SD | 900 | 220–240 | 50/60 | 126 / 151 | 13 | 900×190×225 |
| FRX1210 YDN/SD | 1000 | 220–240 | 50/60 | 136 / 161 | 14.2 | 1000×190×225 |
| FRX1212 YDN/SD | 1200 | 220–240 | 50/60 | 180 / 215 | 16.2 | 1200×190×225 |
| FRX1215 YDN/SD | 1500 | 220–240 | 50/60 | 185 / 244 | 18.8 | 1500×190×225 |
| FRX1218 YDN | 1800 | 220–240 | 50 | 240 | 21.9 | 1800×190×225 |
| FRX1220 YDN | 2000 | 220–240 | 50 | 320 | 24.2 | 2000×190×225 |
Air Velocity, Air Volume & Noise
| Model | Air Velocity (m/s) | Air Volume (m³/h) | Noise (dB) |
|---|---|---|---|
| FRX1209 YDN/SD | 11–12 | 1,780 | ≤45 |
| FRX1210 YDN/SD | 11–12 | 1,977 | ≤47 |
| FRX1212 YDN/SD | 11–12 | 2,370 | ≤47 |
| FRX1215 YDN/SD | 11–12 | 2,970 | ≤47 |
| FRX1218 YDN | 11–12 | 3,560 | ≤50 |
| FRX1220 YDN | 11–12 | 3,960 | ≤51 |
Motor & Protection
<
| Model | Volt (V) | Watt (W) | Amp (A) | RPM | IP |
|---|---|---|---|---|---|
| FRX1209 YDN/SD | 220–240 | 70 | 0.7 | 1300 | IP54 |
| FRX1210 YDN/SD | 220–240 | 70 | 0.7 | 1300 | IP54 |
| FRX1212 YDN/SD | 220–240 | 90 | 1.0 | 1380 | IP54 |
| FRX1215 YDN/SD | 220–240 | 120 | 1.1 | 1330 | IP54 |
| FRX1218 YDN | 220–240 | 130 | 1.35 | 1350 | IP54 |
| FRX1220 YDN | 220–240 | 130 | 1.35 | 1350 | IP54 |
Installation & Safety
- Install horizontally, as close to the top of the doorway as possible; overlap door width by ~100 mm each side.
- Mount on a solid surface; ensure no gaps between air curtain, mounting plate, and wall.
- Outlet height ≥2.3 m; observe local fire/building codes and clearances.
- Electrical: fixed wiring with an all-pole disconnect (≥3 mm contact gap); qualified personnel only.
- Two-speed control with key switch (Low/High); press OFF to stop.
Options & Accessories
- BMS Integration: RS-485 (Modbus RTU) 9600 8-N-1. Monitor ON/OFF, fan speed, door sensor, fire link; door-sensor cut-off delay & auto-restart via BMS.
- Door Sensor (DOS-30): Typical operate 0–15 mm, release ≈16 mm (magnet dependent).
- IR Remote: Optional remote control for convenient operation.
- Custom Colors: RAL palette on request (availability dependent).
Care & Maintenance
- Monthly: Check intake grille for dust/debris.
- Every 3–6 months: Clean fan blades & motor housing.
- Annually: Inspect electrical connections and fasteners.
- Cleaning: Power OFF, wipe exterior with mild detergent, vacuum intake; ensure fully dry before reconnecting.
What’s in the Box
- New Dynamic air curtain (selected model) with mounting brackets.
- User/installation instructions.
- Optional: Door sensor, IR remote, BMS kit (if ordered).
