2-Drawers Under Broiler Counters Chiller - 60HZ
2-Drawers Under Broiler Counters Chiller - 60HZ
Precision Under Broiler Counters — HUBC Series
Maximize kitchen efficiency with Precision Under Broiler Counters, designed to fit seamlessly beneath chargrills and griddles. These heavy-duty refrigerated drawers provide quick access to chilled ingredients exactly where chefs need them, reducing congestion and non-productive time in the cooking line. Proudly manufactured in the UK, they combine robust build quality with advanced refrigeration systems for demanding commercial kitchens.
Key Features
- Stainless steel interior & exterior
- Front breathing & rear venting refrigeration system — operates in up to 43ºC ambient
- GN 1/1 and/or GN 2/1 gastronorm drawer configurations
- R290 refrigerant with zero ODP polyurethane insulation
- +1ºC to +4ºC refrigerator temperature range
- Electronic controller with easy-read LCD screen
- Heat resistant worktop carries up to 150kg (evenly spread)
- Rifle bore coated evaporators and off-cycle defrost
- Integrated flush door handles for ergonomic use
- Hi/Lo audio-visual temperature alarms
- Condensing unit safety system protects compressor
- Heavy-duty brake & swivel castors for mobility
- Waste heat recovery condensate vaporiser system
- Optional: single deep drawer or Precision Connect smart monitoring
Specifications
| Model | Drawer Configuration | Net Usable Volume (L) | Temperature Range | Dimensions (WxDxH mm) | Weight (kg) | Refrigerant | Energy Class |
|---|---|---|---|---|---|---|---|
| HUBC411 | 4 x GN1/1 | 71 | +1 / +4ºC | 1345 x 780 x 610 | 105 | R290 | A |
| HUBC412 | 2 x GN1/1 + 2 x GN2/1 | 104 | +1 / +4ºC | 1670 x 780 x 610 | 126 | R290 | B |
| HUBC422 | 4 x GN2/1 | 139 | +1 / +4ºC | 1995 x 780 x 610 | 140 | R290 | B |
Care Instructions
Keep ventilation areas clear when plinth mounted. Clean drawers and gaskets with mild detergent. Regularly check condensers to prevent blockages. Ensure the worktop load does not exceed 150kg. Always disconnect power before performing maintenance.
